Din Rail Mounted 15VDC 2A Output 30W Switching Power Supply DR-30W-15VDC
Features:
Competitived price,high reliability
105 Degree C output capacitor
AC input power suitable for the world
Soft-start current,reduce the AC input impact effectively
Short circuit protection,overload protection
Small size,light weight
100% full load burn-in test
Installed with EMI filter,minimun wave
DC Output: 15V 2A
Wave and Noise: 240mVp-p
Inlet Stability: +/-0.5%
Load Stability: +/-0.5%
Efficiency: 82%
AC Input Voltage Range: 85~264VAC, 120-370VDC
AC Inrush Current: Cold-start current 15A/115V 30A/230V
Overload Protection: 105%~160% constant current limiting, auto recovery
Over Voltage Protection: 115%~135% rated output voltage
Setup Rise Hold Up Time: 800ms 60ms 50ms/230VAC at full load
Withstand Voltage: I/P-O/P I/P-FG O/P-FG: 500VDC/100M&Omega
Safety Standards: Design refer to GB4943,UL60950,EN60950
EMC Standards: Design refer to GB9254,UL55022,Class B
